0,26 € netto
Solarix SXKD-5E-UTP-LSOH UTP cat. 5e LSOH Dca 305m (box)
Precio
93,48 €
114,98 € IVA incluido
favoriteAñadir a la lista de deseos
Installation Cable Solarix Category 5E UTP LSOH Dca s1 d2 a1
Supplied as a part of complete Solarix Category 5E solution, these cables represent one of the key elements for safety and economical data transfers. All parameters exceed requirements specified by the ANSI/TIA 568C.2, ISO/IEC 11801, and EN 50173 performance standards. The cable conductor is AWG 24 bare copper wire with high density polyethylene insulation. Sheath material is supported by different types of CPR rated compounds – i.e. PVC (reaction to fire Eca), LSOH (reaction to fire Dca s1 d2 a1), LSOHFR (reaction to fire B2ca s1 d1 a1), and PE (reaction to fire Fca).
Specification
| SXKD-5E-UTP-LSOH | |
| LSOH Sheath | Reaction to fire Dca s1 d2 a1 |
| Applicable Standards | iSo/ieC 11801, ieC 61156-5, eN 50173-1, eN 50173-2, eN 50288-2-1/eN 50288-3-1 |
| Conductor Type and Size | Bare copper wire 0.50 mm ± 0.005 mm |
| Insulation | HDPE |
| Wire Diameter with Insulation | 0,88 mm |
| Cable Diameter | 5 mm |
| Weight | 31 kg/km |
| Colour | Purple RAL 4005 |
| NVP | 68% |
| Propagation delay | 535 ns/100 m |
| Delay skew | ≤ 45 ns/100 m |
| Storage Temperature | -20 to +60 °C |
| Operation Temperature | -20 to +60 °C |
| Installation Temperature | 0 to +50 °C |
| Transmission Characteristics acc. to Category 5E (at 20 °C) | |||||||
| f (MHz) | Attentuation (dB/100m) | NEXT (dB) | PSNEXT (ns/100m) | Prop. delay (ns/100m) | ACR-F (dB/100m) | PSACR-F (dB/100m) | Return loss (dB) |
|---|---|---|---|---|---|---|---|
| 1 | 1,94 | 83,24 | 82,43 | 534,95 | 76,30 | 72,75 | 32,03 |
| 4 | 3,89 | 71,20 | 69,89 | 516,29 | 64,02 | 60,40 | 33,38 |
| 8 | 5,52 | 68,88 | 66,19 | 510,89 | 58,02 | 53,00 | 35,09 |
| 10 | 6,18 | 69,88 | 66,88 | 509,48 | 55,08 | 51,28 | 36,05 |
| 16 | 7,83 | 66,11 | 63,11 | 507,05 | 52,09 | 49,08 | 43,10 |
| 20 | 8,77 | 66,90 | 63,82 | 506,03 | 49,66 | 46,58 | 41,27 |
| 25 | 9,81 | 65,40 | 60,58 | 505,18 | 43,65 | 41,21 | 40,07 |
| 31,25 | 11,00 | 57,77 | 55,07 | 504,40 | 45,14 | 52,54 | 39,08 |
| 62,5 | 15,67 | 53,31 | 51,59 | 502,45 | 38,30 | 35,30 | 34,07 |
| 100 | 19,86 | 52,37 | 50,12 | 501,44 | 34,68 | 31,91 | 33,31 |
